TriActive USA Pull Up and Dip Station

TriActive USA Pull Up and Dip Station

by TriActive USA
$2,599.00 - $2,599.00
$2,599.00
$2,599.00 - $2,599.00
$2,599.00

TriActive USA Fitness Equipment

Manufactured in the USA - Built for commercial use in Parks, Schools as well as Correctional Facilities

REQUEST A QUOTE

1) Add products and accessories to your Quote via the Add to Cart / Quote button above

2) You'll see the option to 'Review your Cart / Request Quote'. You can either proceed with your Quote Request from there or continue adding to your request

3) Once you've added all items to your cart, click the 'View Cart / Request Quote' button or select the cart icon in the upper right-hand corner of the screen

4) From your cart, you'll be able to formally request a quote via the blue 'Request Quote' button on the left-hand side below the listed products

Need help?

Call Us: (888) 990-7508

Email Us: Sales@outdoorworkoutsupply.com

INSTALLATION SERVICES

Our dedicated team simplifies the entire process—from helping you select the ideal equipment for your needs to a seamless, professional installation.

See photos of some of our installations - HERE

We pride ourselves on attention to detail and reliability, ensuring your equipment is installed correctly, safely, and promptly. Trust us to handle your project and enjoy your new equipment without hassle or delay.

Contact us for Quotes and Additional Details!

Phone - (888) 990-7508

Email - Sales@outdoorworkoutsupply.com

PRODUCT DESCRIPTION

The Pull Up & Dip Station, a virtually indestructible unit and our #1 seller, is a 2-person unit designed to perform pull ups, dips, knee raises, and pushups for a complete upper body workout. Whether you’re looking to build muscle, increase endurance, or improve overall fitness, our Pull Up & Dip Station provides the perfect combination of functionality and durability.

Specifications

Actual equipment may look different than shown due to frequent design upgrades. This equipment is designed for individuals weighing up to 330 lbs.
  • Dimensions: 51”L X 43”W X 88”H
  • Color: Green or Blue
  • Weight: 175 lbs
  • Assembly: NOT REQUIRED

Warranty

Limited 15-year warranty against manufacturers defect on steel posts, welds, bars and other steel parts on all units that are fully welded, with nonmoving parts.

Product Specification

TriActive USA’s PDIP assumes usage of American standard size tubing, namely:

  • 3” x 3” square tubing x 11ga
  • 3” x 2” rectangular tubing x 11ga
  • 2” Round Tube 11ga
  • 1-1/4” OD round tubing x 11ga
  • ¼” hot rolled flat bar
  • 11ga carbon steel sheet metal

TriActive USA Fitness Equipment does not include any of the following:

  • Exposed cables
  • Hydraulics
  • Plastic seating

Powder Coating Specification

  • Powder coating thickness 6-8 mils. Coatings are tested for 1000 hours of salt spray resistance.
  • Pre-treated
  • Iron phosphate applied
  • Zinc powder applied
  • Functional powder applied
  • Final TGIC powder coat is applied to provide outstanding weathering capabilities

Product Downloads

Product Specs

PRODUCT FEATURES
  • Dimensions: 51”L x 43”W x 88”H
  • Color: Green or Blue
  • Weight: 175 lbs
  • Assembly: NOT REQUIRED
ANCHOR DETAILS

This equipment must be surface mounted onto concrete.

PRODUCT SPECS

Product Specification:

TriActive USA’s PDIP assumes usage of American standard size tubing, namely:

  • 3” x 3” square tubing x 11ga
  • 3” x 2” rectangular tubing x 11ga
  • 2” Round Tube 11ga
  • 1-1/4” OD round tubing x 11ga
  • ¼” hot rolled flat bar
  • 11ga carbon steel sheet metal

TriActive USA Fitness Equipment does not include any of the following:

  • exposed cables
  • hydraulics
  • plastic seating

Powder Coating Specification:

  • Powder coating thickness 6-8 mils. Coatings are tested for 1000 hours of salt spray resistance.
  • pre-treated
  • iron phosphate applied
  • zinc powder applied
  • functional powder applied
  • and final TGIC powder coat is applied to provide outstanding weathering capabilities

Product Downloads:

Product Specs

Installation Sheet

INSTALLATION RESOURCES

Product Specs

Installation Sheet

TRIACTIVE VIDEO OVERVIEW

TriActive Equipment Video Overview - HERE

FREIGHT CONSIDERATIONS

Our TriActive Equipment ships via LTL freight with liftgate service to ensure safe and convenient delivery. This method accommodates the size and weight of the equipment, providing a hassle-free drop-off directly to your location. Please ensure adequate space and access for delivery.

WARRANTY

Limited 10-year warranty on steel posts, welds, bars and other steel parts on all units that are fully welded, with non-moving parts.

Limited 5-year warranty on steel posts, welds, bars and other steel parts for all units with moving parts.
